HSXE2L 2-Flute Long Neck End Mill

1、0.3um ultra fine particles, makes it super wear resistance. 2、AHX coating is a composite multilayer coating base on TiSiN, through special deposition process, the bottom of coating has strong combining ability with the Cemented carbide matrix.And the function layer has compact structure.Compared with the HX coating,the ability of high temperature resistance and wear resistance of AHX coating is significantlly improved.lt's suitable for micro lubrication cutting. 3、lt's suitable for the chilled steels (HRC55-65) and high alloy materials etc.

Key words: tool

Classification:

HSXE2L

Online message

Product Details

Type No.	Dia.	Under Neck Length	Length of Cut	Neck Dia.	Nack Taper Angle	Overall Length	Shank Dia.
HSXE2001L0.3 0450	0.1	0.3	0.07	0.085	12	50	4
HSXE2001L0.5 0450	0.1	0.5	0.07	0.085	12	50	4
HSXE2001L0.75 0450	0.1	0.75	0.07	0.085	12	50	4
HSXE2001L1 0450	0.1	1	0.07	0.085	12	50	4
HSXE20015L0.3 0450	0.15	0.3	0.1	0.13	12	50	4
HSXE20015L0.5 0450	0.15	0.5	0.1	0.13	12	50	4
HSXE20015L0.75 0450	0.15	0.75	0.1	0.13	12	50	4
HSXE20015L1 0450	0.15	1	0.1	0.13	12	50	4
HSXE20015L1.5 0450	0.15	1.5	0.1	0.13	12	50	4
HSXE2002L0.5 0450	0.2	0.5	0.15	0.18	12	50	4
HSXE2002L1 0450	0.2	1	0.15	0.18	12	50	4
HSXE2002L1.5 0450	0.2	1.5	0.15	0.18	12	50	4
HSXE2002L2 0450	0.2	2	0.15	0.18	12	50	4
HSXE2002L2.5 0450	0.2	2.5	0.15	0.18	12	50	4
HSXE2002L3 0450	0.2	3	0.15	0.18	12	50	4
HSXE2003L1 0450	0.3	1	0.2	0.28	12	50	4
HSXE2003L1.5 0450	0.3	1.5	0.2	0.28	12	50	4
HSXE2003L2 0450	0.3	2	0.2	0.28	12	50	4
HSXE2003L2.5 0450	0.3	2.5	0.2	0.28	12	50	4
HSXE2003L3 0450	0.3	3	0.2	0.28	12	50	4
HSXE2003L3.5 0450	0.3	3.5	0.2	0.28	12	50	4
HSXE2003L4 0450	0.3	4	0.2	0.28	12	50	4
HSXE2004L1 0450	0.4	1	0.3	0.37	12	50	4
HSXE2004L1.5 0450	0.4	1.5	0.3	0.37	12	50	4
HSXE2004L2 0450	0.4	2	0.3	0.37	12	50	4
HSXE2004L2.5 0450	0.4	2.5	0.3	0.37	12	50	4
HSXE2004L3 0450	0.4	3	0.3	0.37	12	50	4
HSXE2004L3.5 0450	0.4	3.5	0.3	0.37	12	50	4
HSXE2004L4 0450	0.4	4	0.3	0.37	12	50	4
HSXE2004L5 0450	0.4	5	0.3	0.37	12	50	4
HSXE2004L6 0450	0.4	6	0.3	0.37	12	50	4
HSXE2004L8 0450	0.4	8	0.3	0.37	12	50	4
HSXE2004L10 0450	0.4	10	0.3	0.37	12	50	4
HSXE2005L1 0450	0.5	1	0.35	0.46	12	50	4
HSXE2005L1.5 0450	0.5	1.5	0.35	0.46	12	50	4
HSXE2005L2 0450	0.5	2	0.35	0.46	12	50	4
HSXE2005L2.5 0450	0.5	2.5	0.35	0.46	12	50	4
HSXE2005L3 0450	0.5	3	0.35	0.46	12	50	4
HSXE2005L3.5 0450	0.5	3.5	0.35	0.46	12	50	4
HSXE2005L4 0450	0.5	4	0.35	0.46	12	50	4
HSXE2005L4.5 0450	0.5	4.5	0.35	0.46	12	50	4
HSXE2005L5 0450	0.5	5	0.35	0.46	12	50	4
HSXE2005L6 0450	0.5	6	0.35	0.46	12	50	4
HSXE2005L7 0450	0.5	7	0.35	0.46	12	50	4
HSXE2005L8 0450	0.5	8	0.35	0.46	12	50	4
HSXE2005L9 0450	0.5	9	0.35	0.46	12	50	4
HSXE2005L10 0450	0.5	10	0.35	0.46	12	50	4
HSXE2006L1.5 0450	0.6	1.5	0.45	0.56	12	50	4
HSXE2006L2 0450	0.6	2	0.45	0.56	12	50	4
HSXE2006L2.5 0450	0.6	2.5	0.45	0.56	12	50	4
HSXE2006L3 0450	0.6	3	0.45	0.56	12	50	4
HSXE2006L3.5 0450	0.6	3.5	0.45	0.56	12	50	4
HSXE2006L4 0450	0.6	4	0.45	0.56	12	50	4
HSXE2006L4.5 0450	0.6	4.5	0.45	0.56	12	50	4
HSXE2006L5 0450	0.6	5	0.45	0.56	12	50	4
HSXE2006L6 0450	0.6	6	0.45	0.56	12	50	4
HSXE2006L7 0450	0.6	7	0.45	0.56	12	50	4
HSXE2006L8 0450	0.6	8	0.45	0.56	12	50	4
HSXE2006L9 0450	0.6	9	0.45	0.56	12	50	4
HSXE2006L10 0450	0.6	10	0.45	0.56	12	50	4
HSXE2006L12 0450	0.6	12	0.45	0.56	12	50	4
HSXE2007L2 0450	0.7	2	0.5	0.66	12	50	4
HSXE2007L4 0450	0.7	4	0.5	0.66	12	50	4
HSXE2007L6 0450	0.7	6	0.5	0.66	12	50	4
HSXE2007L8 0450	0.7	8	0.5	0.66	12	50	4
HSXE2007L10 0450	0.7	10	0.5	0.66	12	50	4
HSXE2008L2 0450	0.8	2	0.6	0.76	12	50	4
HSXE2008L3 0450	0.8	3	0.6	0.76	12	50	4
HSXE2008L4 0450	0.8	4	0.6	0.76	12	50	4
HSXE2008L5 0450	0.8	5	0.6	0.76	12	50	4
HSXE2008L6 0450	0.8	6	0.6	0.76	12	50	4
HSXE2008L7 0450	0.8	7	0.6	0.76	12	50	4
HSXE2008L8 0450	0.8	8	0.6	0.76	12	50	4
HSXE2008L10 0450	0.8	10	0.6	0.76	12	50	4
HSXE2008L12 0450	0.8	12	0.6	0.76	12	50	4
HSXE2008L16 0450	0.8	16	0.6	0.76	12	50	4
EPDSE-2009-6-ATH	0.9	6	0.7	0.85	12	50	4
EPDSE-2009-8-ATH	0.9	8	0.7	0.85	12	50	4
EPDSE-2009-10-ATH	0.9	10	0.7	0.85	12	50	4
HSXE2010L3 0450	1	3	0.75	0.95	12	50	4
HSXE2010L4 0450	1	4	0.75	0.95	12	50	4
HSXE2010L5 0450	1	5	0.75	0.95	12	50	4
HSXE2010L6 0450	1	6	0.75	0.95	12	50	4
HSXE2010L7 0450	1	7	0.75	0.95	12	50	4
HSXE2010L8 0450	1	8	0.75	0.95	12	50	4
HSXE2010L9 0450	1	9	0.75	0.95	12	50	4
HSXE2010L10 0450	1	10	0.75	0.95	12	50	4
HSXE2010L12 0450	1	12	0.75	0.95	12	50	4
HSXE2010L14 0450	1	14	0.75	0.95	12	50	4
HSXE2010L16 0450	1	16	0.75	0.95	12	50	4
HSXE2010L18 0460	1	18	0.75	0.95	12	60	4
HSXE2010L20 0460	1	20	0.75	0.95	12	60	4
HSXE2010L22 0460	1	22	0.75	0.95	12	60	4
HSXE2012L6 0450	1.2	6	1	1.14	11	50	4
HSXE2012L8 0450	1.2	8	1	1.14	11	50	4
HSXE2012L10 0450	1.2	10	1	1.14	11	50	4
HSXE2012L12 0450	1.2	12	1	1.14	11	50	4
HSXE2012L16 0450	1.2	16	1	1.14	11	50	4
HSXE2014L6 0450	1.4	6	1.1	1.34	11	50	4
HSXE2014L12 0450	1.4	12	1.1	1.34	11	50	4
HSXE2014L16 0450	1.4	16	1.1	1.34	11	50	4
HSXE2015L4 0450	1.5	4	1.2	1.42	11	50	4
HSXE2015L6 0450	1.5	6	1.2	1.42	11	50	4
HSXE2015L8 0450	1.5	8	1.2	1.42	11	50	4
HSXE2015L10 0450	1.5	10	1.2	1.42	11	50	4
HSXE2015L12 0450	1.5	12	1.2	1.42	11	50	4
HSXE2015L14 0450	1.5	14	1.2	1.42	11	50	4
HSXE2015L16 0450	1.5	16	1.2	1.42	11	50	4
HSXE2015L18 0460	1.5	18	1.2	1.42	11	60	4
HSXE2015L20 0460	1.5	20	1.2	1.42	11	60	4
HSXE2015L25 0460	1.5	25	1.2	1.42	11	60	4
HSXE2015L30 0475	1.5	30	1.2	1.42	11	75	4
HSXE2015L35 0475	1.5	35	1.2	1.42	11	75	4
HSXE2016L6 0450	1.6	6	1.3	1.52	11	50	4
HSXE2016L8 0450	1.6	8	1.3	1.52	11	50	4
HSXE2016L12 0450	1.6	12	1.3	1.52	11	50	4
HSXE2016L16 0450	1.6	16	1.3	1.52	11	50	4
HSXE2018L6 0450	1.8	6	1.4	1.72	11	50	4
HSXE2018L8 0450	1.8	8	1.4	1.72	11	50	4
HSXE2020L4 0450	2	4	1.6	1.9	11	50	4
HSXE2020L6 0450	2	6	1.6	1.9	11	50	4
HSXE2020L8 0450	2	8	1.6	1.9	11	50	4
HSXE2020L10 0450	2	10	1.6	1.9	11	50	4
HSXE2020L12 0450	2	12	1.6	1.9	11	50	4
HSXE2020L14 0450	2	14	1.6	1.9	11	50	4
HSXE2020L16 0450	2	16	1.6	1.9	11	50	4
HSXE2020L18 0460	2	18	1.6	1.9	11	60	4
HSXE2020L20 0460	2	20	1.6	1.9	11	60	4
HSXE2020L25 0460	2	25	1.6	1.9	11	60	4
HSXE2020L30 0475	2	30	1.6	1.9	11	75	4
HSXE2020L35 0475	2	35	1.6	1.9	11	75	4
HSXE2020L40 0475	2	40	1.6	1.9	11	75	4
HSXE2020L50 04100	2	50	1.6	1.9	11	100	4
HSXE2025L8 0450	2.5	8	2	2.4	11	50	4
HSXE2025L10 0450	2.5	10	2	2.4	11	50	4
HSXE2025L12 0450	2.5	12	2	2.4	11	50	4
HSXE2025L16 0450	2.5	16	2	2.4	11	50	4
HSXE2025L20 0460	2.5	20	2	2.4	11	60	4
HSXE2025L25 0460	2.5	25	2	2.4	11	60	4
HSXE2025L30 0475	2.5	30	2	2.4	11	75	4
HSXE2025L35 0475	2.5	35	2	2.4	11	75	4
HSXE2025L40 0475	2.5	40	2	2.4	11	75	4
HSXE2025L50 0475	2.5	50	2	2.4	11	100	4
HSXE2030L8 0660	3	8	2.4	2.9	11	60	6
HSXE2030L10 0660	3	10	2.4	2.9	11	60	6
HSXE2030L12 0660	3	12	2.4	2.9	11	60	6
HSXE2030L16 0660	3	16	2.4	2.9	11	60	6
HSXE2030L20 0660	3	20	2.4	2.9	11	60	6
HSXE2030L25 0675	3	25	2.4	2.9	11	75	6
HSXE2030L30 0675	3	30	2.4	2.9	11	75	6
HSXE2030L35 0675	3	35	2.4	2.9	11	75	6
HSXE2030L40 06100	3	40	2.4	2.9	11	100	6
HSXE2030L50 06100	3	50	2.4	2.9	11	100	6
HSXE2040L12 0660	4	12	3.2	3.9	11	60	6
HSXE2040L16 0660	4	16	3.2	3.9	11	60	6
HSXE2040L20 0660	4	20	3.2	3.9	11	60	6
HSXE2040L25 0675	4	25	3.2	3.9	11	75	6
HSXE2040L30 0675	4	30	3.2	3.9	11	75	6
HSXE2040L35 0675	4	35	3.2	3.9	11	75	6
HSXE2040L40 06100	4	40	3.2	3.9	11	100	6
HSXE2040L45 06100	4	45	3.2	3.9	11	100	6
HSXE2040L50 06100	4	50	3.2	3.9	11	100	6
HSXE2050L20 0660	5	20	4	4.85	11	60	6
HSXE2050L25 0675	5	25	4	4.85	11	75	6
HSXE2050L30 0675	5	30	4	4.85	11	75	6
HSXE2050L40 06100	5	40	4	4.85	11	100	6
HSXE2050L50 06100	5	50	4	4.85	11	100	6
HSXE2060L20 0660	6	20	4.8	5.85	11	60	6
HSXE2060L30 0675	6	30	4.8	5.85	11	75	6
HSXE2060L40 06100	6	40	4.8	5.85	11	100	6
HSXE2060L50 06100	6	50	4.8	5.85	11	100	6
